BU9833GUL-W series is a serial EEPROM of I C BUS interface method. 1.7V single power source action and actions
Datasheet
Serial EEPROM Series Standard EEPROM
WLCSP EEPROM
BU9833GUL-W (2Kbit)
● General Description
2
available at 400kHz.
● Features
Completely conforming to the world standard I C BUS. All controls
2
available by 2 ports of serial clock (SCL) and serial data (SDA)
Other devices than EEPROM can be connected to the same port,
saving microcontroller port.
Actions available at 400kHz clock (1.7V to 5.5V)
1.7 to 5.5V single power source action most suitable for battery use.
Page write mode useful for initial value write at factory shipment.
Auto erase and auto end function at data rewrite.
Low current consumption
At write action (5V) : 1.2mA (Typ.)
At read action (5V) : 0.2mA (Typ.)
At standby action (5V) : 0.1 μ A (Typ.)
Write mistake prevention function
Write (write protect) function added.
Write mistake prevention function at low voltage.
Data rewrite up to 1,000,000times.
Data kept for 40 years.
Noise filter built in SCL / SDA terminal
Shipment data all address FFh.
● Page write
● Package W(Typ.) x D(Typ.) x H(Max.)
VCSP50L1
1.27mm x 1.50mm x 0.55mm
Product number
BU9833GUL-W
● BU9833GUL-W
Number of pages
16Byte
Type
BU9833GUL-W
Capacity
2Kbit
Bit format
256×8
Power source
voltage
1.7V to 5.5V
Package
VCSP50L1
○ Product structure ： Silicon monolithic integrated circuit
○ This product is not designed protection against radioactive rays
www.rohm.com
?2012 ROHM Co., Ltd. All rights reserved.
TSZ22111 ? 14 ? 001
1/24
TSZ02201-0R2R0G100450-1-2
04.SEP.2012 Rev.001
